EM2
The Entrust EM2 Direct-to-Card Printer is all about value and versatility. With dual-sided printing, secure card encoding capabilities, and USB and ethernet connectivity, it’s the perfect budget-friendly printer for a variety of applications such as:
• Corporate IDs
• Student IDs
• Retail gift and loyalty card
• Membership ID cards
• Transportation cards
Key Features
Small footprint
Efficient
Versatile
Affordable
Secure card option
Resources
Technical Specifications
| Name | Specifications |
|---|---|
| Print technology | Dye sublimation |
| Print capabilities | Single- or dual-sided |
| Print resolution | 300 dots per inch |
| Print speed | Single-sided full-color (YMCKT): up to 225 cards per hour (cph) Single-sided monochrome: up to 880 cph Dual-sided: ask your sales representative |
| Card capacity | Input hopper: 125 cards Output hopper: 25 cards Reject hopper: 10 cards |
| Card sizes | Thickness: 0.01 in. — 0.04 in. (0.25 mm — 1.016 mm) Dimension: CR-80, CR-79 |
| Operating environment | 60° F — 95° F (15°C — 35°C) |
| Physical dimensions | L 17.4 in x W 8.9 in x H 9 in / 44.2 cm x 22.6 cm x 22.9 cm |
| Weight | Single-sided printing: 11.3 lbs. (5.13 kg) |
| Connectivity | USB and Ethernet |
| Warranty | 24 months |
| Magnetic stripe encoding | ISOA/IAT |
| Smart card encoding | Loosely coupled: Contact: ISO7816 T=0 (T=1) (dual-sided only) Contactless: ISO 14443 A/B, ISO 15693, MIFARE, MIFARE*DESFire* EV1/ EV2, HID Prox, iClass, iClass SE, iClass Seos, dual-sided only: Felica |
| Color ribbons | YMCKT 250/500 images ymcKT 650 images YMCKT-KT: 350 images ymcKT-KT: 435 images |
| Monochrome ribbons | Black 1500 images White 1500 images Additional monochrome options available |
Applications
Applications
- EM2 is a smart choice to Instant Issuance & High-volume card printing for many types of application including
Applications
- Corporate IDs
Applications
- Student IDs
Applications
- Retail gift and loyalty card
Applications
- Healthcare IDs & Visitors IDs
Applications
- Transportation cards
