InnomationsSec-Tapy
Sai-Ram’s Innomations (SRI) Management with over 30 years of expertise in Automation Identification and Data Capture (AIDC) and Security domains launching completely in-house developed InnomationsSec-Tapy Controller / InnomationsSec-Tapy Mini Combo to meet current and future needs of Customers from Small businesses to Corporate Houses, Workshops to Industries and Apartments to Smart Cities.
InnomationsSec-Tapy Controller / InnomationsSec-Tapy Mini Combo is the origin of Real-Time data presented conveniently on the Management Dashboards placed at all Key points of Corporate Campuses viz. Lobby, Work Area Entrances, Lifts, Business Rooms, Common Facilities like Canteen, Library, Recreation etc..
Key Features
InnomationsSec-Tapy, Secured Cloud enabled IOT Gadget Combo is the Core building Block for
Instant Time Attendance: InnomationsSec-Tapy Timez
Real-time Access Control Monitoring for secured, critical zones: InnomationsSec-Tapy Accez
Campus Payments as and when required: InnomationsSec-Tapy Trans
Tracking Job Performance: InnomationsSec-Tapy Trans
Combination of any of two Services or more: InnomationsSec-Tapy Tranz
InnomationsSec-Tapy is uniquein the Industry to start with one or more services above and gradually migrating to All-in-One Solution with InnomationsSec-Apps
InnomationsSec-Timez ,
InnomationsSec-Accez,
InnomationsSec-Trans,
InnomationsSec-Tranz, so on….
RFID Smartcard can be….
Corporate Employee ID
Campus Student ID
Club Member ID
Event Visitor ID or
Contract Vendor ID
Resources
Technical Specifications
| Name | Specifications |
|---|---|
| InnomationsSec-Tapy Master Controller | MicroController:STM32F407VET6 Communication Interface: RS485/RS232 Communication Protocol: TCP/IP SD Card Storage: Installed 8GB Industrial Grade Transactions stores up to 4GB. Visual Indications: 3 LEDS One for Mode Status, Second for Access and Third for Void. Audio: Buzzer indication on Booting. Diagnosis Indication: LCD –Reader Status, LCD & LED for Server to Controller Health Check. Input Voltage & Current:12V-3Amps Validation Mode Switching: Automatic Switching to Standalone Mode and Sever Mode Transactions Sync: Real-time |
| Environmental | Operating Temperature: 5 to 55 Deg. C |
| SMPS | Output: uninterrupted 13.8 DC, 1.5 Amps. Operating AC Power supply: 100 Vac to 270 Vac. Internal rechargeable 12V/4.5 AH or 1.3 AH Lead Acid Battery. Controller & Readers operation time: 12V-1.3AH:1.30 min to 2hrs for Time & Attendance on Battery 12V-4.5AH:9-10 Hrs Backup for Time & Attendance on Battery Auto charge on mains supply. Low battery cut-off to avoid battery deep discharge. Over current protection. |
| LCD Display | 20×4 character LCD Display with Blue Backlight |
| InnomationsSec-Tapy Field Upgradable | Attendance EM Lock-2 Doors Turnstile-2 No’s Boom Barriers-2 No’s |
| Enclosure | Visual indications on front Panel. Mountable on wall. Metal Body. Powder Coated-Dark Grey Physical Dimensions:308 (L)*298(D)*80mm(W) |
| InnomationsSec-Tapy Mini Reader | Input Voltage& Current: 5Vdc-0.30 mA(Max) Frequency: 13.56 Mhz(High Frequency) Reading Distance: 5-10 Cms (Depends on Card Type) Communication Protocol: RS485/RS232 Physical Dimensions:90*70*28 mm Indications: 3 LED’s for Reader Health, Accept, Void and Buzzer for Each Swipe |
| Contactless Cards | Mi-fare Classic 1K,4K Ultralight Mifare SE+ Desfire |
Applications
InnomationsSec-Tapy Timez, a very user-friendly Combo, quickly captures online Time Data with Flash of an RFID smart card, as a fall-back provides offline data capture as well.
InnomationsSec-Tapy Accez, Secured Online Access Control Combo handy for Security Officers and Management to control people access to premises with ease and supports offline Access control validation in case of network break-out.
InnomationsSec-Tapy Trans Secured, Smart online Payment combo with programmable Pay with a flash of an RFID smart card, typically for Canteens / Clubs / Food Courts etc…
InnomationsSec-Tapy Tranz Secured, Smart online Payment & Access Combo with programmable Payment and Access with a Flash of an RFID Smart card for Corporate and Apartment complexes, Parking Lots, Gyms, Swimming Pools, Events etc.. at ease.
